※ Use and Characteristics
1. Gantry frame structure is adopted, with high intensity and without deformation.
2. The cutting head can automatically move horizontally, with excellent operating visual field and safe and reliable operation.
3. The lifting position of pressing board can be freely set to reduce idle travel and enhance work efficiency.
4. The movement of cutting head is controlled by automatic speed variation to realize flexible movement with high speed and accurate positioning and without impact.
5. Differential oil way is adopted to allow rapid and convenient cutting.
6. Products of special specifications can be customized.
※ Technical Specification
| Model | HSD250 | HSD250A | HSD250B | HSD500 | HSD500A | HSD500B |
| Maximum cutting force(KN) | 250 | 250 | 250 | 500 | 500 | 500 |
| Working table (mm) | 1600*500 | 1800*500 | 2000*500 | 1600*500 | 1800*500 | 2000*500 |
| Travel head size (mm) | 500*500 | 500*500 | 500*500 | 550*550 | 550*550 | 550*550 |
| Adjustable stroke(mm) | 5-150 | 5-150 | 5-150 | 5-150 | 5-150 | 5-150 |
| Motor power(KW) | 2.2 | 2.2 | 2.2 | 4.0 | 4.0 | 4.0 |
| Machine’s dimensions(mm) | 2200*620*2000 | 2400*620*2000 | 2600*620*2000 | 2200*620*2000 | 2400*620*2000 | 2600*620*2000 |
| G.W(kg) | 2000 | 2500 | 3500 | 3800 | 4800 |
Automatic Rotary Heand Cutting Machine with Nesting Software
Automatic Die Cutting Machine for Roller and Sheet Materials
Automatic Rotary Die Cutters for Roller Materials PLC System
Converyor Belt Die Cutting Machine with Die Store
CNC Intelligent Hydraulic Die-Cutting Machine
Automatic Feeding and Punching Press Die Machine
FAQ
Which industries are hydraulic cutting machines suitable for?
Hydraulic cutting machines are widely used in industries such as footwear materials, automotive interiors, packaging, textiles, leather, foam, and sporting goods, meeting the need for precision cutting across various materials.
What materials can the cutting machine process?
The equipment is suitable for a wide range of non-metallic materials—including leather, EVA, foam, rubber, textiles, cardboard, and composites—accommodating various thickness and hardness requirements.
Can the cutting machine be customized?
Yes. We provide professional customization solutions based on customer-specific materials, product dimensions, production efficiency, and automation needs to meet specialized processing requirements.
What after-sales services are provided for the cutting machine?
We offer technical consultation, installation guidance, operation training, and maintenance support to help customers quickly resolve operational issues and ensure continuous production.
Is the cutting machine available for export?
Yes. Our products have been exported to markets including Europe, the USA, Japan, and South Korea; we provide equipment packaging and technical services that meet international standards.
What is the delivery lead time for the cutting machine?
Delivery times for standard equipment vary by model, while production schedules for customized equipment are determined based on specific configuration requirements to ensure timely delivery.
